MEAN WELL Power Supply XLG-20 Series Constant Current Mode LED Driver

Product Item : XLG-20 series
Category：LED Driver
Wattage: 21W
Input Voltage: 90 ~ 305VAC
Output Current: 350 ~ 700mA
Output Voltage: 40 ~ 60V
Product description：XLG-20 series is a AC/DC LED driver featuring the constant current mode output. XLG-20 operates from 90~305VAC.
INQUIRY EMAIL

XLG-20 Series - 21W Constant Current LED Driver with Active PFC, Class 2, IP67, 1-10V Dimming

In Stock 5-Year Warranty Constant Current 21W Max IP67 Class 2 Active PFC 1-10V Dimming Type HL

				Key Performance at a Glance

						21W

						Max Power

						89%

						Peak Efficiency

						3

						Current Options

						2

						Version Types

						IP67

						Outdoor Rated

						+80C

						Max Tcase

Product Overview

The MEAN WELL XLG-20 series is a 21W AC-to-DC constant-current (CC) LED driver family with IP67 protection, Class 2 power rating, and Type HL certification for Class I, Division 2 hazardous location lighting. It is designed for LED street lighting, architectural lighting, bay lighting, flood lighting, and industrial lighting.

It accepts universal 90~305VAC input and provides three fixed output current options: 350mA (L-Type), 500mA (M-Type), and 700mA (H-Type). With peak efficiency up to 89%, the driver uses a fanless design and operates at case temperatures from -40C to +80C under free air convection.

The metal enclosure carries an IP67 rating for both indoor and outdoor use. Two function versions are available: Blank (fixed output current) and B (3-in-1 dimming: 1~10Vdc / 10V PWM / resistor). The B-type dimming circuit is galvanically isolated from the output for safety. The driver also features no-load/standby power consumption below 0.5W.

Protection includes short-circuit hiccup mode with automatic recovery. The driver complies with global lighting safety and EMC standards including UL8750 Type HL, CSA, ENEC, AS/NZS, BS EN/EN, GB/T, JIS, EAC, IS 15885, and KC, and is backed by a 5-year warranty. Note: a switch must be installed between the mains and the LED driver to meet the latest ErP regulations.

Product Images

XLG-20 series LED driver dimension diagram

Technical Specifications

Output ratings for the XLG-20 series. All values measured at 230VAC, rated current, 25C unless noted.

Model	Rated Current	Rated Power	CC Region	Open Circuit Max	Efficiency
XLG-20-L	350mA	18.9W	32.4 ~ 54V	60V	89%
XLG-20-M	500mA	21W	25.2 ~ 42V	50V	88.5%
XLG-20-H	700mA	21W	18 ~ 30V	40V	88%

Version Types

Type	IP	Output Adjustment	Dimming	Availability
Blank	IP67	Fixed output current	None	In Stock
B	IP67	Fixed	3-in-1 (1~10Vdc / 10V PWM / resistor)	In Stock

Input & Protection (All Versions)

Input Voltage Range	90~305VAC \| 47~63Hz
Active PFC / THD / AC Current	PF>=0.97/115V, >=0.95/230V, >=0.91/277V at full load \| THD<20% (@load>=50%/115VAC,230VAC; @load>=75%/277VAC) \| 0.3A/115V, 0.2A/230V, 0.2A/277V
Inrush / Leakage / Breaker	Cold start 5A (twidth=350us measured at 50% Ipeak) / 230VAC per NEMA 410 \| 42 units on 16A breaker (B or C type) at 230VAC \| <0.75mA/277VAC
Set Up / Rise Time	500ms / 115VAC, 150ms / 230VAC (typ.)
No-Load / Standby Power	<0.5W
Protection	Short circuit: hiccup mode, auto-recovery after fault removed \| Current tolerance: ±8.0% \| Current ripple: <20% \| Line regulation: <±3%
Surge Immunity	Line-to-earth: 4KV \| Line-to-line: 2KV
Operating / Storage Temp	Tcase=-40~+80C (refer to derating curve) \| Storage -40~+80C \| Temp coefficient ±0.03%/C (0~60C)
Vibration / Humidity	10~500Hz, 5G, 12min/cycle, X/Y/Z 72min each \| 20~95% RH non-condensing
Isolation	3.75KVac I/P-O/P, 2KVac I/P-FG, 1.5KVac O/P-FG
EMC Emission / Immunity	EN55015/CISPR15, J55015, GB/T17743; Harmonic Class C (@load>=50%); EN61000-3-3 \| Immunity: EN61000-4-2 Level 3, EN61000-4-3 Level 3, EN61000-4-4 Level 3, EN61000-4-5 (4KV line-earth, 2KV line-line), EN61000-4-6 Level 3, EN61000-4-8 Level 4, EN61000-4-11, EN61547
Lifetime / MTBF / Size	>50,000 hours at Tcase<80C \| 5721.2K hrs (Telcordia SR-332) / 747.1K hrs (MIL-HDBK-217F, 25C) \| 95 x 63 x 30mm \| Blank 0.34Kg / B-Type 0.35Kg

Safety Standards & Certifications

Safety Standards	UL8750 (Type HL), CSA C22.2 No. 250.13-12, ENEC, AS/NZS IEC 61347.2.13:2013, AS/NZS 61347.1:2016, BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384, GB/T19510.1, GB/T19510.213, J61347-1(H29), J61347-2-13(H29), EAC TP TC 004, IS 15885(Part 2/Sec13), KC61347-1, KC61347-2-13 \| IP67
Withstand Voltage	I/P-O/P: 3.75KVAC \| I/P-FG: 2.0KVAC \| O/P-FG: 1.5KVAC
Insulation Resistance	I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC / 25C / 70% RH
EMC Emissions	BS EN/EN55015 (CISPR15), J55015, GB/T17743; Harmonic BS EN/EN61000-3-2 Class C (@load>=50%); BS EN/EN61000-3-3
EMC Immunity	BS EN/EN61547, BS EN/EN61000-4-2 Level 3, BS EN/EN61000-4-3 Level 3, BS EN/EN61000-4-4 Level 3, BS EN/EN61000-4-5 (4KV line-earth, 2KV line-line), BS EN/EN61000-4-6 Level 3, BS EN/EN61000-4-8 Level 4, BS EN/EN61000-4-11

Key Features

Constant Current Output -- Direct LED Drive
XLG-20 is a pure constant-current Class 2 LED driver. Choose L-Type (350mA / 32.4~54V), M-Type (500mA / 25.2~42V), or H-Type (700mA / 18~30V) to match your LED module.

Three Current/Voltage Options
L-Type delivers 18.9W; M-Type and H-Type deliver 21W. Each model has a matched constant-current region and maximum open-circuit voltage for safe LED string drive.

2 Version Types -- Blank / B
Blank-Type provides fixed output current. B-Type adds isolated 1~10Vdc / 10V PWM / resistor dimming. Both are IP67 rated.

Class 2 + Type HL + IP67
Class 2 power limits simplify installation. UL8750 Type HL certification supports hazardous location lighting. Sealed metal housing supports indoor and outdoor use.

Active PFC + Global Certifications
PF>=0.97 at 115V and THD<20% keep installations compliant. UL/CSA/ENEC/AS/NZS/GB/JIS/EAC/IS/KC certifications enable worldwide deployment.

5-Year Warranty + Ultra-Compact Size
Backed by a 5-year warranty. The compact 95 x 63 x 30mm metal housing fits space-constrained fixtures. No-load power is below 0.5W.

Frequently Asked Questions

What is the difference between XLG-20-L, XLG-20-M and XLG-20-H?

The suffix indicates the output current and voltage range. L-Type = 350mA default, 32.4~54V CC region, 18.9W. M-Type = 500mA default, 25.2~42V CC region, 21W. H-Type = 700mA default, 18~30V CC region, 21W. All share the same IP67 enclosure, protection set, and global certifications.

Is XLG-20 a constant-voltage driver?

No. XLG-20 is a constant-current LED driver. It maintains a fixed output current while the output voltage varies within the specified constant-current region based on the LED load. Do not use it to power LED modules that require a constant-voltage supply.

Which version type should I choose?

Blank-Type for simple fixed-current installations. B-Type for smart lighting with 1~10Vdc / 10V PWM / resistor dimming. The dimming port is isolated from the output for safety.

What does Class 2 and Type HL mean?

Class 2 means the output is limited to a safe power level, simplifying wiring requirements. Type HL means the driver is UL8750 listed for use in Class I, Division 2 hazardous location lighting fixtures when installed per manufacturer instructions.

Can I use XLG-20 with LED modules that have built-in drivers?

No. XLG-20 is designed for direct LED string connection. It is not suitable for LED modules with built-in constant-voltage or additional drivers. Direct LED connection is recommended.
